| 產品說明 |
|
| 特點 |
|
| 型號 | 測量范圍 | 精度 (mm) | 深度 (mm) | 環規 (mm) |
|---|---|---|---|---|
| XTL6M-BT | 6-8 | 0.004 | 58 | 8.00 |
| XTL8M-BT | 8-10 | 8-10 | 58 | 8.00 |
| XTL10M-BT | 10-12.5 | 0.004 | 58 | 12.50 |
| XTL12M-BT | 12.5-16 | 0.004 | 62 | 12.50 |
| XTL16M-BT | 16-20 | 0.004 | 62 | 20.00 |
| XTL20M-BT | 20-25 | 0.004 | 66 | 20.00 |
| XTL25M-BT | 25-35 | 0.004 | 66 | 35.00 |
| XTL35M-BT | 35-50 | 0.004 | 80 | 35.00 |
| XTL50M-BT | 50-65 | 0.005 | 80 | 50-65 |
| XTL65M-BT | 65-80 | 0.005 | 80 | 65.00 |
| XTL80M-BT | 80-100 | 0.005 | 85 | 80.00 |
